The BRObox family of professional USB recorders enable easy recording and copying of high-quality H.264 video to up to nine USB drives at a time. This provides the ability to promptly share live event content for review and distribution to a team or clientele.

Visit the official BRObox page

If you would like more information, please contact us at sales@mtasales.com.au or contact either Tony in Melbourne or Chris in Brisbane.

Chris Wylie

0434 077 874

chrisw@mtasales.com.au

Tony Hambling

(03) 9819 6455

tony@mtasales.com.au


The brobox family

Supporting multiple input formats, the BRObox provides a competitive technology to the market that addresses many everyday commercial needs.

The Family is comprised of Little Sis, Little Bro and Big Bro, each providing the same powerful capabilities in media distribution, management and recording, only differing in channel count. Whatever your requirements, there is a Broadcast Recording Organiser to suit.


 features

Each model comes with 9 USB ports for batch copying

Internal HD capable of storing 192 - 24 hours of video

big bro - 4 SDI inputs, 8 XLR audio inputs

little sis - 2 SDI inputs, 4 XLR audio inputs

little bro - 1 SDI input, 2 XLR audio inputs


applications

broadcast


PORTFOLIO COPY

Entertainers can be provided a recording to take away post event that is playable on any device that accepts USB Disk.

entertainment


COACHING RESOURCE

Rehearsals can be reviewed with the embedded timecode to pinpoint observations, keeping viewers on the same frame.

events


TAKE-AWAY

Copies of an event can be included into packages or sold separately to allow patrons to enjoy the entertainment beyond the event date.

sports


TRAINING REVIEW

Training and other sporting activities can be recorded to allow analysis  with specific video frames for easy reference.



Dedicated User interface

The BRObox comes with its own Graphic User Interface to manage and monitor inputs, routing and recording. Depending on the model, up to 4 video feeds can be monitored at a time along with the audio on a customisable meter. By default, embedded audio on SDI inputs is preserved to USB but there is also the option to embed another feed by patching a source to the XLR analogue audio inputs, and then selecting within the routing page.


Specs:

  • Weight: 9kg
  • Power: 100-240 V AC, 3.5 Amps. 60-50 Hz, IEC connector
  • Temp: 5 - 40°C / 41 - 104 °F
  • Video Storage Capacity: Low: 192 hrs, Medium: 96 hrs, High: 48 hrs, Super: 24 hrs
  • Video File Codec: H264 with AAC audio codec
  • SD Formats: 525i29.97 NTSC, 625i25 PAL
  • HD Formats: 720p50, 720p59.94, 720p60, 1080p23.98, 1080p24, 1080p25, 1080p29.97, 1080p30, 1080PsF23.98, 1080PsF24, 1080PsF25, 1080PsF29.97, 1080PsF30, 1080i50, 1080i59.94, 1080i60
  • SDI Compliance: SMPTE 259M (SD) and 292M (HD)
  • Certification: Certified for use in 27 countries
